Features
TV SIF stage use
Low insertion loss
Wide bandwidth ceramic trap
Excellent spurious suppression characteristics
Frequency range from 3.58MHz to 6.5MHz
RoHS Compliant
Specifications
| Part Number |
Trap Attenuation (at nominal frequency) (dB) |
20dB Attenuation Band Width (kHz)
|
20dB Attenuation Band Width (kHz)
|
| XT3.58MB | 25 |
|
≧40(70) |
| XT4.43MB | 30 |
|
≧50(80) |
| XT4.5MB | 35 |
|
≧70(120) |
| XT5.5MB | 35 |
|
≧90(120) |
| XT5.74MB | 35 |
|
≧90(120) |
| XT6.0MB | 20 |
|
≧90(120) |
| XT6.5MB | 20 |
|
≧90(120) |
| XT4.5MB | 20 | ≧30 | 35 |
| XT5.5MB | 20 | ≧30 | 20 |
